UOTEK 10/100M to 1-Port RS-232/485/422 Serial Device Server

UT-6001 series serial device server provides serial port to Ethernet port function. It converts RS-232/485/422 port to TCP/IP port, allows bidirectional data transmission between RS-232/485/422 & TCP/IP. This makes the serial device support TCP/IP function. It supports IEEE 802.3AF standard, the POE function greatly extend the communication of serial devices.

Feature

CPU: 150MHz

Memory: data buffer space each port≥60KB

Ethernet port: RJ45 10/100M (built-in 2KVElectromagnetic isolation, surge 10/700us common mode:2,000V/differential mode 1,000V) auto MDI/MDI-X

POE standard: supports IEEE802.3AF

Protocol: IP, ICMP, UDP, TCP, HTTP, TELNET, DNS, DHCP

System: Windows /XP/2003/win7/win8/win10 32/64bit

Operating mode: VCOM, TCP SERVER, TCP CLIENT, UDP, Serial Telnet Mode, Remote Pair mode, RFC 2217

Number of master: Supports 4 hosts simultaneous connection

Configuration: Web browser, VCOM Utility, Telnet

Number of serial port: 1, DB9 connector & 3.81-4PIN terminal block

Serial port protection: RS-232/485/422 surge 10/700us common mode/differential mode 0.5KV

Baud rate: 300-921,600bps

Check bits: None, Odd, Even, Mark, Space

Data bits: 7, 8

Stop bits: 1, 1.5, 2

Data flow control: RTS/CTS, XON/XOFF

Power voltage: 5V, 12-36VDC, 12-60VDC, with optional POE, surge 1.2/50us common mode:2,000V/differential mode 1,000V

Operating current: 350mA@12V max

Power port: 5.08mm 3-pin terminal block & DC plug

Operating temperature: -40°C ~ +85°C

Storage temperature: -40°C ~ +85°C

Relative humidity: 5% ~ 95%RH, non-condensing
