Product name：

UOTEK 10/100M to 2-Port RS-232/485/422 Serial Device Server

Model： UT-6802A

● Provide virtual COM driver software under Windows;

● With a serial port, it can be connected to various serial devices such as terminals, Modem, bar code machine, cash register, ISDN, terminal adapter, serial printer and PC, and can realize remote control function;

● With a Reset key, which is used to restore the default factory state.

● With 10/100M adaptive Ethernet port;

● Each serial port provides 5 signals, including RXD, TXD, RTS, CTS, GND;

● 32-bit embedded 120MHz CPU, powerful overall performance;

● Support ARP, IP, ICMP, UDP, TCP, HTTP, DHCP, MODBUS protocols.

Overview Parameter Download Get a quote

UT-6802A series serial communication server, also called terminal server or serial server, is a converter between asynchronous serial port RS232/422/485 and Ethernet. It is an independent intelligent device with CPU, embedded OS and complete TCP/IP protocol stack. Complete bidirectional transparent transmission of data between RS232/422/485 and Ethernet, allowing RS232/422/485 serial devices to connect to the network immediately.
Support dynamic IP (DHCP) and static IP, support gateway and proxy server, can transmit data through the Internet. It provides two-way transparent transmission of data and realizes the function of serial port to TCP/IP, and the user does not need to make any modification to the original system. Internally integrate ARP, IP, TCP, HTTP, ICMP, SOCKET, UDP, MODBUS and other protocols. Provide an interface for custom protocol access. All programs have setup wizards, so you can use them as long as you know how to use a computer.

CPU	32bit LX6 240MHZ microprocessor
RAM	520K
Ethernet interface	10/100M (embedded 1.5KV electromagnetic isolation) adaptive MDI/MDI-X Ethernet interface, interface mode RJ45
Serial port	RS-232/485/422 three-in-one or RS-485/422
Serial interface	RJ45 or 4pin 3.81 plug-in terminal
Indicator light	Power indicator PWR, running indicator RUN, serial port transceiver indicator DATA.
Power interface	DC-005 DC socket or 3Pin 5.08 terminal power supply mode, built-in anti-reverse connection protection, to avoid damage to equipment by wrong connection of positive and negative
Power range	DC12~57.6V
Function button	1 factory reset button RESET
Max. power consumption	12V@150mA
Housing	Metal shell, protection grade IP30
Installation method	Default DIN-rail installation, fixed piece installation (wall-mounted optional)
Operating environment	Storage temperature: -40~85°C Operating Temperature: -40~85°C Relative humidity: 5% ~95% (non-condensing)
Altitude	0~4000m
Dimensions L×W×H	100mm×80.8mm×30mm (excluding mounting parts)
Net weight	248g
